JT65 Mini Excavator | Heavy-Duty Performance, Compact Reach

Yanmar Engine Options | 6,044mm Digging Radius | Professional 0.23m³ Bucket

Powerhouse for Professional Excavation

The JT65 mini excavator is engineered for contractors who require serious digging power and extended reach without committing to a full-size machine. Featuring high-output Yanmar engine options and a robust 0.23 m³ bucket, this model handles deep utility work, complex foundations, and large-scale site prep with ease.

Technical Specifications

Model	JT65
Engine Brand	Yanmar 494 / 498
Rated Power	36.3 / 42.4 / 42.5 kW
Bucket Capacity	0.23 m³
Swing Speed	12 r/min
Max. Digging Radius	6,044 mm
Max. Digging Depth	3,506 mm
Max. Digging Height	5,157 mm
Max. Unloading Height	3,692 mm
Min. Swing Radius	3,022 mm

Why Choose the JT65 Mini Excavator?

Extended Working Range: The massive 6,044 mm digging radius and 3,506 mm depth allow you to tackle deep foundations and long trenching lines with minimal machine repositioning.
High-Performance Power: Choose from three Yanmar engine configurations (up to 42.5 kW) for the torque and sustained power required for heavy-duty daily excavation.
Efficient Material Handling: With a 0.23 m³ high-capacity bucket and 3,692 mm unloading height, it ensures rapid spoil removal and high-efficiency loading into trucks.
Precision Maneuverability: 12 r/min swing speed and a balanced 3,022 mm minimum swing radius provide the perfect blend of agility and control in crowded construction zones.
Versatile Professionalism: Designed for the contractor who needs a reliable machine capable of switching between deep trenching, heavy site cleanup, and drainage work seamlessly.
